EDM Machine DRO
>
Durable EDM Machine Digital Readout , 50Hz-60Hz Magnetic Scale DRO Kit
All Category

SINO Digital Readout System

Digital Readout Kits

3 Axis Digital Readout

CNC Vertical Machining Center

2 Axis Digital Readout

Single Axis Digital Readout

Glass Linear Encoder

Magnetic Linear Encoder

Milling Machine DRO

Lathe Machine DRO

EDM Machine DRO

Boring Machine DRO

Optical Angle Encoder

CNC Machine Accessories
Durable EDM Machine Digital Readout , 50Hz-60Hz Magnetic Scale DRO Kit
  • name
  • name

Durable EDM Machine Digital Readout , 50Hz-60Hz Magnetic Scale DRO Kit

Brand Name: SINO
Model Number: SDS 200, KA-300, KA-500, KA-600
MOQ: 1 set
Price: Negotiable
Packaging Details: Carton
Payment Terms: T/T, L/C
Detail Information
Product Description
Detail Information
Place of Origin:
Guangzhou, CHINA
Certification:
CE,RoHS
Item Name:
2 Axes TFT Large Size Lathe Machine Readout Unit
Usage:
2 Axes Large Scale Lathe
System:
2 Axes TFT DRO SDS 200
Scale Model:
Encoder: KA-300/KA-500/KA-600
Signal:
Encoder: TTL / EIA-422-A Square Wave
Resolution:
Encoder: 0.005/0.001/0.0005 Mm
DRO Mounting:
On Lathe's Electric Cabinet
Meas. Travel:
Encoder: 70-3000mm
Display:
TFT Colorful Screen
Voltage:
50Hz - 60Hz, 100V - 240V For DRO
Supply Ability:
3000 sets per month
Highlight:

EDM Machine Digital Readout

,

50Hz Machine Digital Readout

,

60Hz Magnetic Scale DRO Kit

Product Description

SINO 2 axes metal TFT large size lathe machine readout unit SDS 200 mounting on electric box with two linear encoders



The readout unit is special for 2 axis large scale lathe positioning.



The SDS 200 is a colorful screen DRO that should be mounting on the lathe's electirc cabinet.



The KA-600 linear encoder should be for axis Z, and KA-300 or KA-500 linear encoder should be for axis X.



The standard cable of the linear encoders is 3M, sometimes extension cable is necessary for large size lathe's installation.

The length of extension cable is 1M to 10M, is the optioned accessory.

Durable EDM Machine Digital Readout , 50Hz-60Hz Magnetic Scale DRO Kit 0



Package list:



Item name TFT large size lathe machine readout unit
Digital Readout (DRO) SDS 200
Linear scale for axis Z KA-600 1000-3000mm
Linear scale for axis X KA-300 / KA-500 270-520mm
Rack for DRO Rack for lathe
Protection cover for Z scale Type M
Protection cover for X scale Type D / H
Bracket for scales

T-bracket (1set) / KA-500 bracket (1pc)
Others Cable / Screws / Manual
