Product Details:
|
| Item Name: | Magnetic Linear Encoder SINO KA800 | Application: | For Mill Lathe EDM CNC |
|---|---|---|---|
| Sealing Protection: | IP53 | Output Signal: | RS-442/TTL |
| Length: | 3000-5000mm | Resolution: | 1/5 Micron |
| Cross Section: | 32*57 | Distance Of Poles: | 5mm |
| Cable: | 5 Cores Or 8 Cores | Supply Voltage: | 5VDC±5%、24VDC±5% |
| High Light: | KA800 Magnetic Linear Encoder,Digital Readout Magnetic Linear Encoder,EDM Magnetic Linear Encoder |
||
Magnetic Linear Encoder SINO KA800 Digital Readout Scale Test Intrusment For Mill Lathe EDM CNC CE RoHS
KA800MC-5 magnetic scale is mainly suitable for processing and measuring occasions with low and medium precision requirements, such as wood and stone processing.
The tape is composed of MB50 tape with 5+5mm pitch and protective stainless steel tape. It is smoothly pasted on a special aluminum shell with a special protective steel tape for better oil-proof, waterproof, and dustproof protection to improve service life.
The small size sensor just occupies a small space to make the installation to be easier.
Please do not do the following
1. Any mechanical reprocessing (cutting, drilling, surface milling, etc.).
2. Any modification to the Sensor.
3. Any illegal operations.
4. Impact and external pressure.
5. The rubber part of the tape is exposed
Technical parameters of tape
| Specification | 5+5mm |
| Accuracy at 20℃ | 0.02mm/m |
| Width | 10mm |
| Thickness | 1.45mm |
| Maximum measuring length | 100m |
| Expansion coefficient | 10.5*10-6/k |
| Minimum bending radius | 130mm |
| Operating temperature | -20℃～85℃ |
| Storage temperature | -20℃～85℃ |
Detail Information:
All linear scales will be tested before delivery. Here is a sample of a scale's testing report.
