Product Details:
|
| Item Name: | 4 Axes LCD Milling Machine Digital Readout Milling Head Package | Usage: | 4 Axes Mill Machine Positioning |
|---|---|---|---|
| System: | 4 Axes DRO SDS 200 For Milling Axis Z | Scale Model: | Linear Scales: KA-500, KA-300, KA-600 |
| Signal: | Linear Scales: TTL / RS422 | Resolution: | Linear Scales: 0.005mm/0.001mm |
| Voltage: | AC 100V-240V And 50-60Hz | Meas. Travel: | 70-3000mm |
| High Light: | 4 Axis Milling Machine DRO,Multi Function Milling Machine DRO,Milling Machine DRO Digital Readout |
||
SINO 4 axis metal LCD milling machine DRO kit SDS 200 with four linear scales
Beside axis X/Y/Z, there is an additional axis Z1 that special for the milling head's positioning.
So, this set is special for 4 axis milling machine requirement.
One 4-axis metal LCD display DRO SDS 200 with four linear scales.
The model and travels of the scales are on the max. travel of the mill.
Package list:
| Item name | 4 axis LCD milling machine DRO kit |
| Digital Readout (DRO) | SDS 200 |
| Linear scale for axis X | KA-300 or KA-600: 70-3000mm |
| Linear scale for axis Y | KA-300 or KA-600: 70-3000mm |
| Linear scale for axis Z | KA-300 or KA-600: 70-3000mm |
| Linear scale for axis Z1 | KA-500: 70-870mm |
| Rack for DRO | L400 |
| Protection cover for X scale | Type M or Type C |
| Protection cover for Y scale | Type D |
| Protection cover for Z scale | Type D |
| Accessory for Z Milling head | KA-500 milling head accessory (1 set) |
| Bracket for scales | T-bracket (2 sets) |
| Others | Cable / Screws / Manual |
