Product Details:
|
| Name: | Digital Readout Sino SDS3MS Syastem | Number Of Axis: | 3 Axis |
|---|---|---|---|
| Usage: | Various Types Of 2 Axis Proposals | Suitable For: | Lathe Milling Machine System |
| Name 2: | Counter For Digital Readout | Voltage: | AC 100~240V |
| Signal: | Input: TTL / RS422 | Color: | Grey Color |
| Warranty: | 1 Year | ||
| High Light: | SDS3MS SINO Lathe Milling Machine,SINO Lathe Milling Machine |
||
Sino SDS2-3MS Lathe Milling Machine DRO Digital Readout SDS3MS Display
DRO SDS3MS is a multipurpose gauge with a 3-coordinate numerical display.
This gauge can change to the appropriate function using a different machine tool simply by altering the parameters.
SINO SDS3MS digital readout parameters
1. The voltage range: AC 85 v ~ 250 v / 50 hz ~ 60 hz
2. 15 w power consumption: 25 va
3. Coordinate the number: a coordinates, two coordinates, three coordinates
4. Show that signed seven display (two or three axis) output data information using eight meters words show symbols
5. Weight: 2 kg
6. The input signal: TTL, EIA - 422 open collector output signal, convenient interface with a programmable controller.
7. Allow the input signal frequency: > 100 KHZ
8. To connect a resolution: 10 microns, 5 microns, 2 microns, 1 mu m, 0.5 microns
Basic Functions
mm/inch Transformation Absolute/Relative Transformation
Mid-split Function Simple “R” Function
Smooth “R” Function Divide the perimeter of circle
Save 200 workpiece zero points Divide holes on an oblique line
Mathematics calculation Tool diameter compensation
Bevel process Zero location autorest
| 1 PC | 3 Axis digital readout SDS3MS |
| 1 PC | Transparent cover |
| 1 PC | Instruction Manual (English) |
| 1 PC | Cable |
Product image /photos:
The rack in the picture is optioned, not standard product.
