SINO SDS6-2V Magnetic Scale DRO Kit 3 Axis Glass Linear Optical Encoder Milling Machine

Name: SINO SDS6-2V Magnetic Scale DRO Kit 3 Axis Glass Linear Optical Encoder Milling Machine
Brand: Guangzhou Sino International Trade Co.,Ltd
SKU: SDS6-2V
Availability: InStock

Brand Name:	SINO
Model Number:	SDS6-2V
MOQ:	1 PC
Price:	Negotiable
Packaging Details:	Carton
Payment Terms:	T/T, L/C

Detail Information

Product Description

Detail Information

Place of Origin:

Guangzhou, CHINA

Certification:

CE,RoHS

Name:

Digital Readout SDS6-2V For Lathe Grinding Cutting Machine

Number Of Axis:

3 Axis Display Readout Counter

Color:

Grey

Display:

7 Digits LED

Signal:

Digital Readout: TTL / RS422

Voltage:

Digital Readout: AC100-240V / 50-60Hz

Suitable For:

Milling Machine, Lathe, Boring Machine, EDM Machine, Grinding Machine

Supply Ability:

1000 pcs per month

Highlight:

3 Axis Magnetic Scale DRO Kit

3 Axis Glass Linear Optical Encoder

Product Description

SINO SDS6-2V Magnetic Scale DRO Kit 3 Axis Glass Linear Optical Encoder Milling Machine

Sino Digital Readout DRO Functions have been improved

Extend the calculator function: Users should have the ability to select the number of digits to be placed behind the radix point, such as 3, 4, or 5, in addition to the calculator function being provided to the DRO programs for the EDM, lathe, and milling machines.

The system has a maximum of 40 sections of non-linear error correction in order to boost machining precision.

3. The number of decimal digits in inch display mode can be selected.

There are two options for the number of decimal digits: four or five. The demand for lengthy scales can be met with four digits, and the condition for high precision can be met with five digits. Please refer to the manual for further information on the differences.

Specifications:

Range of supply voltage: AC 80V to 260V; 50Hz to 60Hz, US plug available

Energy usage: 15 VA

Operating range: 0 to 45 degrees Celsius

Storage range: -30 to 70 degrees Celsius

Square wave TTL/RS422 input signal allowed for readout

Frequency of the allowed input signal: less than 5MHz

Display resolution: 5 m1, 1 m, 5 m, and 1 m

Digital display angle minimum resolution: 0.0001 pulse

Packaging List :

1 PC	3 Axis LED digital readout SDS6-3V
1 PC	Protection cover
1 PC	Instruction Manual (English)
1 PC	Cable

Product image /photos:

SINO SDS6-2V Magnetic Scale DRO Kit 3 Axis Glass Linear Optical Encoder Milling Machine 0

SINO SDS6-2V Magnetic Scale DRO Kit 3 Axis Glass Linear Optical Encoder Milling Machine 1

The rack in the picture is optioned, not standard product.

SINO SDS6-2V Magnetic Scale DRO Kit 3 Axis Glass Linear Optical Encoder Milling Machine 2
