Product Details:
|
| Item Name: | SINO KA200-350mm Optical Scale Ruler In Miniature | Application: | Utilizing Digital Readout Technology And A Small Linear Encoder |
|---|---|---|---|
| Usage: | Sensor Position Scaling | Customized Length: | 30mm/40mm/50mm/60mm |
| Length: | 70mm/80mm/90mm/100mm | Material: | Aluminum |
| Function: | EDM/Lathe/Grinding/Boring Machine/Milling Machine | Resolution: | 0.5μm/1μm/5 μm |
| High Light: | Sensor Position Linear Glass Scale,5 Micron Linear Glass Scale |
||
Sino KA200 30-360 Linear Glass Scale 16*16 Cross Section 5micron Linear Encoder
package contains:
KA200-30mm-360mm short linear glass scale, one piece.
Based on the KA-500 grating ruler, the KA-200 grating ruler features an upgraded internal and external architecture.
Since the micro grating ruler is made to have a smaller structural size than the KA-500, it is suitable for applications with constrained installation and placement on smaller devices. The length of use ranges from 30 to 360 mm.
installation utilizing a D, X, and H type ruler cover and a KA-200 full cover grating ruler
L0: Effective measuring length of encoder L1: Dimension of encoder mounting hole
L2: Encoder overall dimension
Detail Information:
All linear scales will be tested before delivery. Here is a sample of a scale's testing report.
