SINO YSV-1160 3 Axis Metal CNC Vertical Machining Center With DDS Transmission Type

SINO YSV-1160 3 Axis Metal CNC Vertical Milling Tool with DDS Transmission Type

SINO YSV-1160 Innovative 3-Axis Metal CNC Vertical Milling Equipped With DDS Transmission Type

YSV-1160 machine features:

1. Machining center with excellent performance
2. Taiwan's frequency converter tool magazine reduces tool change time to 1.4 seconds, improving processing efficiency
3. Fast and accurate positioning with strong torque production on all three axes
4. Standard spindle motor equipped with an 11-15KW high-torque generalized motor, suitable for heavy cutting
5. Machine tool parts sourced from a well-known brand and renowned factory, featuring cutting-edge configuration

YSV-1160 optical machine features:

• Utilizes German Rexroth line rail with a width of 45mm
• The Y-axis span is 745mm, providing wide coverage
• Strong stiffness and supported by 6 sliding seats on the X axis, enabling effective cutting
• PMI outer diameter 40mm C3 grade screws used on the three axes
• NSK original bearings (3062) in a 3+2 mode with pre-tensioning treatment to prevent thermal displacement
• High-rigidity BBT spindle with 150mm outer diameter and ring spray design
• Original Taiwanese ultra-high-speed cutting cylinder with a cutting time of 0.28 seconds
• Precise HT300 high-grade cast iron bed

Installation, commissioning, acceptance, and training:

• Service engineer will visit the customer's plant for installation, commissioning, and on-site training
• Option for sending operators to the company's location for initial training, followed by on-site training during installation and commissioning
• Acceptance includes examining items that can be checked on-site and inspecting items not meeting requirements, based on the supplier's accuracy inspection table
• Buyer can dispatch workers to the supplier's factory for inspection and acceptance

After-sales service concept:

• Pre-sales service includes providing processing alternatives, tool and fixture selection, option configuration, and machine tool selection
• Maintenance response time within two hours with a dedicated service crew and service van
• Parts inventory available at the company's facility, ensuring fast repair component availability
• Free maintenance services for machine tools within the warranty period, affordable and fair maintenance fees for tools outside warranty
• Equipment management and maintenance process planned based on customer needs
• Transparent billing based on actual cost after the warranty period, emphasizing openness and fairness
• Special department for old users, monitoring machine tool usafishingge and promptly addressing maintenance problems
• General manager serves as the director of the after-sales service department, ensuring real-time monitoring of maintenance service quality and protecting customer rights.
