|Item Name:||2 Axes Metal LCD Full Touch Screen Milling Machine DRO 0.005mm Resolution Practical||Usage:||Small Boring Machine|
|System:||Small Size Milling Readout SDS200s||Scale Model:||Glass Linear Rulers: KA-600, KA-300|
|Signal:||Linear Scale: TTL / RS422||Resolution:||Linear Rulers: 0.005mm/0.001mm|
|Voltage:||Readout Power: AC 100V-240V/Customer's Requirement||Meas. Travel:||Linear Encoder:1000-3000mm, 70-1020mm|
|Condition:||New||After-sales Service Provided:||Online Support|
Full Touch Screen Milling Machine DRO,
2 Axes Milling Machine DRO,
0.005mm Resolution Milling Machine DRO
Two Axes Metal LCD Full Touch Screen Milling Machine DRO 0.005mm Resolution Practical
2 Axes Metal LCD Full Touch Screen Milling Machine DRO 0.005mm Resolution Practical
Upgrade your milling machine with the LCD Full Touch Screen DRO (Digital Readout) system, featuring a high-resolution of 0.005mm and practical functionality for precise measurement and positioning. Designed for metal milling applications, this DRO system provides accurate readings and intuitive touch screen operation for convenient usage.
LCD full touch screen interface for easy and intuitive operation
Two axes (X and Y) measurement capability for metal milling machines
High-resolution of 0.005mm for precise measurement and positioning
Practical functionality designed for practical usage in metalworking applications
Accurately measures and displays the position of the mill's X and Y axes
Provides precise positioning for achieving desired milling results
Easy-to-use touch screen interface for convenient operation
Robust construction suitable for metalworking environments
The kit is specifically designed to meet the needs of big 2-axis milling machines.
Two common linear rulers, the KA-600 or the KA-300, and one LCD display readout (SDS200).
Linear ruler KA-600: 1000 - 3000mm
Linear ruler KA-300: 70 - 1020mm
Accuracy and Precision: DROs are designed to provide accurate and precise measurements. The resolution of the system determines the smallest increment it can measure, and higher-resolution systems offer finer measurement capabilities.
Display Units: DROs feature digital display units that show the measured values. These units can have multiple screens to display various measurements simultaneously or toggle between different axes or functions. The displays may use LED, LCD, or other technologies.
|Item name||4 axes small size metal LCD milling machine Readout kit|
|Digital Readout (DRO)||SDS 200s|
|Linear scale for axis X||1000-3000mm|
|Linear scale for axis Y||70-1020mm|
|Rack for DRO||L400|
|Protection cover for X scale||Type M|
|Protection cover for Y scale||Type D|
|Bracket for scales||T-bracket (1 or 2 sets, depend on the size)|
|Others||Cable / Screws / Manual|
Functions for milling machine:
All linear scales were tested before delivery. Here is a sample of a scale's test report.
