The TTL/RS422 Signal Ka Series For Lathes Has A Resolution Of 0.1um/5um/1um Linear Glass Scale Encoder

All Category

SINO Digital Readout System

Digital Readout Kits

3 Axis Digital Readout

CNC Vertical Machining Center

2 Axis Digital Readout

Single Axis Digital Readout

Glass Linear Encoder

Magnetic Linear Encoder

Milling Machine DRO

Lathe Machine DRO

EDM Machine DRO

Boring Machine DRO

Optical Angle Encoder

CNC Machine Accessories

The TTL/RS422 Signal Ka Series For Lathes Has A Resolution Of 0.1um/5um/1um Linear Glass Scale Encoder

Brand Name:	SINO
Model Number:	KA200/KA300/KA500/KA600/KA700
MOQ:	1 set
Price:	Negotiable
Packaging Details:	Carton
Payment Terms:	T/T, L/C

Detail Information

Product Description

Detail Information

Place of Origin:

Guangzhou, CHINA

Certification:

CE,RoHS

Item Name:

SINO Linear Grating Ruler

Function:

Lathe Machine /milling Machine

Measure Length (mm):

30-360/70-1020/70-470/100-3000/170-1240

Material:

Metal

Resolution:

0.1μm/0.5μm/1μm/5μm

Housing Cross Section（mm）:

16*16/25*34/18*20/30*43/40*42/

Biggest Speed（m/min）:

Sealing Protection:

IP53

Output:

TTL/RS422

Warranty Period:

1 Year

Accuracy:

±3μm/±5μm/±10μm(L<1m; 20±1 ℃)

Reference Point:

One In Each 50mm

Supply Ability:

3000 sets per month

Highlight:

5um Linear Glass Scale Encoder

1um Linear Glass Scale Encoder

RS422 Linear Glass Scale Encoder

Product Description

The TTL/RS422 Signal Ka Series For Lathes Has A Resolution Of 0.1um/5um/1um Linear Glass Scale Encoder

Grating ruler complete set includes:

linear scale, screws, dust cover, operation manual, installation accessories

Model

1.KA-200:Accuracy:±3μm/±5μm/±10μm(L<1m; 20±1 ℃),Measure Length:30mm-360mm,Resolution:1μm/5μm

2.KA-300:Accuracy:±3μm/±5μm/±10μm(L<1m; 20±1 ℃),Measure Length:70mm-1020mm,Resolution:0.1μm/0.5μm/1μm/5μm

3.KA-500:Accuracy:±3μm/±5μm/±10μm(L<1m; 20±1 ℃),Measure Length:70mm-470mm,Resolution:0.5μm/1μm/5μm

4.KA-600:Accuracy:±3μm/±5μm/±10μm(L<1m; 20±1 ℃),Measure Length:1000mm-3000mm,Resolution:0.1μm/0.5μm/1μm/5μm

5.KA-700:Accuracy:±3μm/±5μm/±10μm(L<1m; 20±1 ℃),Measure Length:170mm-1240mm,Resolution:0.1μm/0.5μm/1μm/5μm

Our grating ruler has the following characteristics

1. Fast movement, exceeding 60 meters per minute

2. The sliding components of the bearing can perform minimal frictional motion and effective repeated placement along the grating glass.

3. The signal cable adopts multi-layer isolation steel wire mesh and metal soft shell protection, which has good waterproof and anti-interference performance.

4. Due to the use of anodizing technology in aluminum alloy materials, the sturdy chrome plated alloy scales and protruding parts of the body are wear-resistant.

5. By using a grating to locate the position, linear rulers can be used on various digital reading machines to assist in internal processing.

6. Personalized components make the installation, maintenance, and repair of linear encoders very easy, and they are waterproof, dustproof, and have a long lifespan

7. The linear encoder uses a glass precision measurement grating as the measurement reference to ensure high accuracy

installation using a KA-200 full cover grating ruler with a D, X, and H type ruler cover

The TTL/RS422 Signal Ka Series For Lathes Has A Resolution Of 0.1um/5um/1um Linear Glass Scale Encoder 0

L0: Effective measuring length of encoder L1: Dimension of encoder mounting hole

L2: Encoder overall dimension

Detail Information:

The TTL/RS422 Signal Ka Series For Lathes Has A Resolution Of 0.1um/5um/1um Linear Glass Scale Encoder 1

All linear scales will be tested before delivery. Here is a sample of a scale's testing report.

The TTL/RS422 Signal Ka Series For Lathes Has A Resolution Of 0.1um/5um/1um Linear Glass Scale Encoder 3
