Item Name: RS232-C Metal LED Big Lathe Digital Display System With Two Axes Usage: Two-axis Lathe With RS-232-C Interface
System: SDS6-2VF, A Two-axis Digital Display Scale Model: Glass Ruler: KA-300, KA-500, KA-600
Signal: TTL / RS422 Glass Ruler Square Wave Signal Resolution: 0.005mm/0.001mm/0.0002"
DRO Mounting: Slide Part Meas. Travel: Glass Ruler: 70-3000mm
Display: Seven Digits Green LED Voltage: Glass Ruler: 5V, Digital Display: 100V - 240V
High Light:

Multilingual Digital Readout Lathe

,

RS422 Digital Readout Lathe

,

0.001mm Digital Readout Lathe

Digital Readout Lathe Multilingual RS422 Signal With Resolution Of 0.001mm​





This digital display system is unique for placing lathe machines in two axes.


The sliding box of the lathe is where the RS232-C output digital display SDS6-2VF should be mounted.

For axis Z, use the KA-600 ruler; for axis X, use the KA-300 or KA-500 ruler.



Package list:



Item name 2 axis RS232-C lathe machine digital display system
Digital Readout (DRO) SDS6-2VF
Linear scale for axis Z KA-600 1000-3000mm
Linear scale for axis X KA-300/KA500 270-520mm
Rack for DRO Rack for lathe (50C)
Protection cover for Z scale Type M
Protection cover for X scale Type D / H
Bracket for scales

T-bracket (1set) / KA-500 bracket (1pc)

Others Cable / Screws / Manual



Functions for lathe machine:

  1. Diameter to Radius Conversion

  2. Tool Diameter Adjustment

  3. Measurement of Tapers

  4. 200 Tools Storage Room
