1mm Pitch TTL Linear Scale 1 Micron Incremental Linear Encoder

Certification
China Guangzhou Sino International  Trade Co.,Ltd certification
China Guangzhou Sino International  Trade Co.,Ltd certification
Customer Reviews
We purchased SINO products eight years ago. We don't restock the latest batch of DROs until 2022. Using SINO's products greatly facilitates our work. I sincerely hope that SINO can continue to develop and make more accurate products for us.

—— Charles

I'm Online Chat Now

1mm Pitch TTL Linear Scale 1 Micron Incremental Linear Encoder

1mm Pitch TTL Linear Scale 1 Micron Incremental Linear Encoder
1mm Pitch TTL Linear Scale 1 Micron Incremental Linear Encoder 1mm Pitch TTL Linear Scale 1 Micron Incremental Linear Encoder

Large Image :  1mm Pitch TTL Linear Scale 1 Micron Incremental Linear Encoder

Product Details:
Place of Origin: Guangzhou, CHINA
Brand Name: SINO
Certification: CE,RoHS,ISO9001
Model Number: KA800M
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Carton
Delivery Time: 5-8 days
Payment Terms: T/T, L/C
Supply Ability: 3000 sets per month

1mm Pitch TTL Linear Scale 1 Micron Incremental Linear Encoder

Description
Item Name: Linear Magnetic Encoder Strip Usage: Magnetic Encoder Strip That Is Linear
Type: Large, Boring Lathe Scale Model: KA-800M-1mm Pitch
Output Signal: RS422 TTL Resolution: 1 Micron
Cable Length: 3 Meter Standard Measurement Up To: 1000mm
Pitch: 1mm Pitch Sensor: IP67
High Light:

TTL Incremental Linear Encoder

,

1 Micron Incremental Linear Encoder

,

1mm Pitch Incremental Linear Encoder

1mm Pitch TTL Linear Scale 1 Micron Incremental Linear Encoder​





KA800M Magnetic Encoder Advantage



Exceptional accuracy of up to ± 10µm / 300mm or ± 20µm / 1000mm,
Measurement range: 3 to 100 meters
- High resistance to wear and tear; - Low susceptibility to impact, vibration, and pollution (such as dirt and petroleum); and
Exact 1 mm pitch, extended measuring range, contact-free measurement, no backlash issues, easy installation
The following types of facilities are best suited for magnetic scales: large lathes, metalworking facilities, machines for processing stone, and woodworking equipment.
Benefits of Magnetic Scale:
Its robust anti-severe environment capability ensures that it won't get dirty or damaged from the cooling water.
The anti-protective properties of the cooling liquid, metal powder, or dust are quite potent.



Technical parameter



Magnetic Encoders
Reference signal Each 5mm(C)
Pitch 1mm
Ruler tape specifications 5+5mm
Resolution 1µm
Operating voltage 5V+±5%
Cable 5 core or 8 core
Output form TTL or RS-422
Max. Moving speed 30m/min
Operating temperature -20~70℃
High precision of up ± 10µm / 300mm or ± 20µm / 1000mm
Measurement length 3–100m
Humidity 100% Non-condensing
Standard reading head provides cable 3m





Encoder Magnetic Scale Application



Large lathes, grinding machines, milling machines, drilling machines, and electrical discharge machines (EDMs)

Machining centers, woodworking, PVC, glassworking, and material handling equipment



Encoder Magnetic Mcale Application



Heavy lathes, Milling machine, Drilling, Grinder machine, EDM (electrical discharge machine)

Machining Centers, PVC Cutting Machine, Wood Cutting Machine, Glass-working machine, Material handling





Detail image:
