SINO Small Linear Scale KA500 Compact Digital Readout Encoder For Small Lathe Milling Machines

SINO Small Linear Scale KA500 Compact Digital Readout Encoder For Small Lathe Milling Machines

The KA500 Small Linear Scale Digital Readout Optical Encoder is a sophisticated precision measurement tool tailored for small lathes and drilling machines. Its compact design and high accuracy deliver reliable and precise measurements, ensuring accuracy in machining operations.

Features:

Compact Design: The Small Linear Scale KA500 is crafted for small lathe and drilling machines, providing a compact size that integrates effortlessly into confined workspaces.

Digital Readout: Equipped with a built-in digital readout, it delivers clear, easy-to-read measurements for precise monitoring and control of machining processes.

Optical Encoder Technology: Advanced optical encoder technology ensures accurate and consistent measurements, even in demanding conditions.

High Accuracy: The KA500 offers precise measurements, minimizing material waste and boosting overall productivity.

Easy Installation:Designed for straightforward installation, the encoder can be quickly and easily mounted on small lathes or drilling machines.

Functionality:

The Small Linear Scale KA500 Digital Readout Optical Encoder allows users to measure linear displacements with high accuracy on small lathe and drilling machines. It delivers real-time measurements for precise monitoring of the machining process. The advanced optical encoder technology ensures reliable and accurate data, enhancing machining results and productivity.

Usage:
The KA500 is designed for small lathe and drilling machines, making it ideal for precise linear displacement measurements in metalworking, woodworking, jewelry making, and small-scale manufacturing.

Applicable Scenarios:

Small Machine Workshops:The KA500 encoder is perfect for small machine workshops handling lathe and drilling tasks, improving the accuracy and precision of machining processes for superior output.

Small-Scale Manufacturing: For small-scale manufacturing industries, integrating the KA500 with lathe and drilling machines ensures precise measurements, boosting production quality and efficiency.

Package includes:

Glass Linear Scale, 1 Piece, KA500-70mm

Available resolutions: 0.5, 1, and 5 micrometers.

Customized encoder lengths (L0) can be tailored to consumer specifications, ranging from 70mm to 470mm.

L0: Effective measuring length of encoder L1: Dimension of encoder mounting hole

L2: Encoder overall dimension

Operating Guideline

To ensure proper use and safety of the KA series linear encoder:

1. General Description and Safety Considerations: Thoroughly review these sections in Chapter 1 for foundational knowledge and safety guidelines.

2. Chapters 1-3: Installation, testing, and repair professionals must carefully follow and understand all details provided in these chapters.

3. Chapters 4-5: Ensure complete comprehension of every paragraph to understand operational specifics.

4. Safety Advice: Refer to the listed safety advice to ensure safe handling and operation of your linear encoder.

Detail Information:

All linear scales will be tested before delivery. Here is a sample of a scale's testing report.
