Product Details:
|
Item Name: | Two Axes Metal TFT Boring Machine Digital Counter System | Usage: | Two Axes Boring Machining Propose |
---|---|---|---|
System: | TFT Digital Counter SDS5-4V | Scale Model: | KA-600 Series Or KA-300 Series |
Signal: | Square Wave EIA-422-A/RS422 Or TTL | Resolution: | 0.005 / 0.001 / 0.0005 Mm (inch Is Possible) |
Standard Cable: | 3M Long | Meas. Travel: | From 70mm To 3000mm |
Display: | TFT Display / Colorful | Voltage: | 50-60Hz / 100-240V / For Counter & 5V For Scales |
High Light: | Two Axes DRO Digital Readout Kit,ISO9001 DRO Digital Readout Kit,5V Digital Read Out System |
SINO two axes metal TFT boring machine digital counter unit SDS5-4VA with two linear glass scales
This TFT digital counter system is special for two axes boring machining propose.
There is one TFT DRO SDS5-4VA and two KA-series linear glass scales. For big machine, usually KA-600 or KA-300 model.
And the standard cable of the scales is only 3000mm long, sometimes extension cables are necessary for the big machine.
The length of extension cable should be 1M to 10M.
Package list:
Item name | Two axes metal TFT boring machine digital counter system |
Digital Readout (DRO) | SDS5-4VA |
Linear scale for axis X | KA-600 / KA-300: 70-3000mm |
Linear scale for axis Y | KA-600 / KA-300: 70-3000mm |
Rack for DRO | Rack L400 |
Protection cover for X scale | Type D / M |
Protection cover for Y scale | Type D / M |
Bracket for scales |
T-bracket (2 sets) |
Others | Cable / Screws / Manual |
Detail Information:
Pin Description:
All linear scales were tested before delivery. Here is a sample of a scale's test report.
