Product Details:
|
| Name: | Digital Readout Display SDS3MS | Number Of Axis: | 3 Axis Dro |
|---|---|---|---|
| Usage: | 3-Axis Readout | Suitable For: | Lathe Milling Machine System |
| Voltage: | AC 100~240V | Signal: | Input: TTL / RS422 |
| Color: | Grey Color | Warranty: | 1 Year |
| Name 2: | Counter For Digital Readout | ||
| High Light: | SINO Digital Readout Lathe,RS422 SINO Digital Readout Lathe |
||
3-Axis SDS2-3MS SINO Digital Readout Lathe Spark Milling Digital Display
A multipurpose gauge with a numerical display for three coordinates is called a DRO SDS3MS.
By simply changing the parameters, this gauge can be made to perform the necessary function with a different machine tool.
SINO SDS3MS digital readout parameters
1. The voltage range: AC 85 v ~ 250 v / 50 hz ~ 60 hz
2. 15 w power consumption: 25 va
3. Coordinate the number: a coordinates, two coordinates, three coordinates
4. Show that signed seven display (two or three axis) output data information using eight meters words show symbols
5. Weight: 2 kg
6. The input signal: TTL, EIA - 422 open collector output signal, convenient interface with a programmable controller.
7. Allow the input signal frequency: > 100 KHZ
8. To connect a resolution: 10 microns, 5 microns, 2 microns, 1 mu m, 0.5 microns
Basic Activities
mm/inch Transformation Relative/Absolute Transformation
Mid-split Function Basic "R" Function
A fluid "R" function Circle's perimeter is divided.
200 workpieces zero points saved Make holes on a slanted line.
Calculations in mathematics Tool diameter adjustment
Process of bevels Location-based autorest
| 1 PC | 3 Axis digital readout SDS3MS |
| 1 PC | Transparent cover |
| 1 PC | Instruction Manual (English) |
| 1 PC | Cable |
Product image /photos:
The rack in the picture is optioned, not standard product.
